The TW580 is a high‑performance, modular weighing automation controller/indicator, designed for seamless integration into industrial automation systems. It delivers fast, precise weight data and advanced monitoring for static and dynamic weighing applications across manufacturing, logistics, and process industries.
| Parameter | DIN Rail Mount Type | Panel Mount Type | Dustproof Type |
| Housing Type | DIN rail mounting with quick connection for automatic grounding | Panel mounting with detachable display and weighing processing unit | VESA 100 desk/wall/pole mounting |
| Housing Material | ABS plastic | Stainless steel front panel | Stainless steel (including mounting bracket) |
| IP Rating | IP20 | Front panel IP65 | IP66 and IP69K |
| Dimensions (W×H×D) | 40 × 135 × 100 mm | 175 × 94 × 17 mm | 275 × 87 × 200 mm |
| Operating Environment | Certified temperature: -10℃ to 40℃; Operating temperature: -10℃ to 50℃; Relative humidity: 10% to 90%, non-condensing | ||
| Power Supply | 20~28 VDC / 12W; 100–240 VAC / 49–61 Hz | ||
| Power Consumption | 3-6 W (depending on option board configuration) | ||
| Display | 1.04-inch green OLED | 4.3-inch color TFT | |
| Keypad | 4 membrane keys | 5 membrane keys | |
| Sensors | Up to 8 × 350Ω load cells; 1-4 mV/V sensitivity; 5VDC excitation voltage | ||
| Accuracy | Maximum verification scale division: 10000e | ||
| Update Rates | Weight update rate: 960Hz; Weight comparison rate: 960Hz; PLC update rate: 960Hz | ||
| Connectivity | Standard: Modbus TCP (1-port), TCP Server (printing, basic communication, configuration) Optional: Industrial Ethernet (2-port with built-in switch); Supported protocols: Profinet/EtherNet/IP/EtherCAT/Modbus TCP/CC-Link IE Field Basic Optional: Analog output 4-20mA / 0-10V Optional: Modbus RTUOptional: Isolated RS232 + isolated RS422/RS485 (continuous output with CPTZ) | ||
| Digital Input/Output | Digital inputs: Up to 5, polarity selectable, opto-isolatedDigital outputs Up to 8, solid-state relays, max. 150mA | ||
| Application Support | Basic weighing, setpoint control, comparator, level detection, filling, packaging, checkweighing, loss-in-weight, etc. | ||
1.High‑Speed Performance
2.Flexible & Certified Connectivity
3.Modular & Rugged Design
4.Pre‑Programmed Applications
